砂金矿全套重选生产线工艺流程
Alluvial Gold Ore Gravity Separation Production Line · Three Independent Lines · Full Physical Gravity Separation
流线1 · 0-3mm细粒级 Fine Grain
流线2 · 3-10mm中粒级 Medium Grain
流线3 · ＞10mm粗粒级 Coarse Grain
粗选阶段
Roughing Stage
精选阶段
Cleaning Stage
最终产物
Final Product
原矿石
Raw Ore
滚筒分级筛
Rotary Trommel Screen
0-3mm
3-10mm
＞10mm
≤5mm
离心选矿机
Centrifugal Concentrator
6S选矿摇床 No.1
6S Shaking Table
金精矿
Gold Concentrate
尾矿
Tailings
固定淘金溜槽
Fixed Gold Sluice Box
6S选矿摇床 No.2
6S Shaking Table
金精矿
Gold Concentrate
尾矿
Tailings
锤式破碎机
Hammer Crusher
离心选矿机
Centrifugal Concentrator
6S选矿摇床 No.3
6S Shaking Table
金精矿
Gold Concentrate
尾矿
Tailings
销售咨询Sales Contact
Coco
Sales Manager · 销售经理
WhatsApp
+86 18003804329
WeChat 微信
18003804329
工艺说明Process Description
砂金矿重选工艺流程采用三段独立流线设计，根据矿石粒度分级处理，全程物理重力分选，无化学药剂，环保高效。原矿石经滚筒分级筛筛分为0-3mm、3-10mm、＞10mm三个粒级：
· 0-3mm细粒级：采用离心选矿机粗选 + 6S摇床精选，回收率高，精矿品位好；
· 3-10mm中粒级：采用固定淘金溜槽粗选 + 6S摇床精选，处理量大，运行成本低；
· ＞10mm粗粒级：经锤式破碎机破碎至≤5mm后，进入离心选矿机粗选 + 6S摇床精选，确保粗颗粒中金的充分回收。
三条流线最终产出高品质金精矿，尾矿统一排入尾矿库。
· 0-3mm细粒级：采用离心选矿机粗选 + 6S摇床精选，回收率高，精矿品位好；
· 3-10mm中粒级：采用固定淘金溜槽粗选 + 6S摇床精选，处理量大，运行成本低；
· ＞10mm粗粒级：经锤式破碎机破碎至≤5mm后，进入离心选矿机粗选 + 6S摇床精选，确保粗颗粒中金的充分回收。
三条流线最终产出高品质金精矿，尾矿统一排入尾矿库。
Alluvial Gold Gravity Separation Process features three independent lines designed for different ore size fractions, using full physical gravity separation without chemicals, environmentally friendly and efficient. Raw ore is classified by rotary trommel screen into three size fractions: 0-3mm, 3-10mm, and ＞10mm:
· 0-3mm fine fraction: Centrifugal concentrator for roughing + 6S shaking table for cleaning, high recovery rate and good concentrate grade;
· 3-10mm medium fraction: Fixed gold sluice box for roughing + 6S shaking table for cleaning, large capacity and low operating cost;
· ＞10mm coarse fraction: Crushed to ≤5mm by hammer crusher, then processed by centrifugal concentrator + 6S shaking table to ensure full recovery of gold in coarse particles.
All three lines produce high-quality gold concentrate, with tailings discharged to the tailings pond.
· 0-3mm fine fraction: Centrifugal concentrator for roughing + 6S shaking table for cleaning, high recovery rate and good concentrate grade;
· 3-10mm medium fraction: Fixed gold sluice box for roughing + 6S shaking table for cleaning, large capacity and low operating cost;
· ＞10mm coarse fraction: Crushed to ≤5mm by hammer crusher, then processed by centrifugal concentrator + 6S shaking table to ensure full recovery of gold in coarse particles.
All three lines produce high-quality gold concentrate, with tailings discharged to the tailings pond.
