The WSHT-NE Bucket Elevator is a vertical conveying equipment designed for lifting bulk materials from low to high positions in mining, metallurgy, cement, and other industries.
Detailed technical information, working principles and application scenarios. Custom configurations available based on your project requirements.
The WSHT-NE Bucket Elevator is a vertical conveying equipment designed for lifting bulk materials from low to high positions in mining, metallurgy, cement, and other industries....
The WSHT-NE Bucket Elevator is a vertical conveying equipment designed for lifting bulk materials from low to high positions in mining, metallurgy, cement, and other industries.
Featuring a chain-driven bucket system with high tensile strength, the NE series delivers smooth and reliable vertical transportation of various materials including ore, coal, cement, and grain.
Maximum lifting height up to 50 meters for various industrial applications.
Chain-driven buckets provide high conveying capacity up to 300 TPH.
Advanced counterweight tensioning device ensures stable and reliable operation.
Wear-resistant chains and buckets with extended service life reduce downtime.
| Model | Bucket Volume (L) | Lifting Speed (m/s) | Throughput (t/h) | Power (kw) |
|---|---|---|---|---|
| NE-15 | 0.8 | 0.5 | 20-40 | 3 |
| NE-30 | 1.5 | 0.5 | 40-80 | 5.5 |
| NE-50 | 2.5 | 0.5 | 80-120 | 7.5 |
| NE-100 | 4 | 0.5 | 120-200 | 15 |
| NE-200 | 8 | 0.5 | 200-300 | 22 |
Vertical conveying of cement, clinker, and raw meal in cement plants.
Lifting of ore, coal, and mineral concentrates in mining operations.
Coal and limestone conveying in thermal power plant handling systems.
Vertical transport of grains and seeds in food processing facilities.
All WSHT WSHT-NE series equipment undergoes rigorous quality inspection and load testing before delivery. We provide comprehensive after-sales service including installation guidance, operator training, and 24/7 technical support.
Engineered for reliability, built for performance. Every WSHT product reflects our commitment to quality and innovation.
High-grade steel structure & precision CNC machining for long-term reliability in the harshest mining conditions.
Optimized chamber geometry and intelligent design deliver maximum output per hour with minimal downtime.
Advanced engineering reduces power consumption by up to 20% compared to conventional equipment designs.
On-site installation, commissioning, operator training and spare parts supply available worldwide.
Our engineering team will design a tailored solution based on your site conditions, ore characteristics and production targets. Bilingual project management with end-to-end support.
