| Product model | Screen area（m²） | Mesh size (mm) |
Capacity (t/h) | Vibration frequency(min) | Power(kw) | Shape L×W×H (mm) | |
| WSTS-1230 | 3.6 | 0.25-20 | 40-60 | 960 | 2X2.2 | 3140x1640x1680 | |
| WSTS-1530 | 4.5 | 0.25-20 | 60-80 | 960 | 2X4 | 3083x1907x1484 | |
| WSTS-1845 | 8 | 0.25-20 | 100-120 | 960 | 2X5.5 | 4900x2380x2050 | |
| WSTS-2050 | 10 | 0.25-20 | 200-220 | 960 | 4X3.7 | 5415x2685x2042 | |
| WSTS-2448 | 11.5 | 0.25-20 | 220-250 | 960 | 4X4.5 | 4915x3085x2242 |
1. User-Friendly Design
✓ Lightweight construction for easy transport/installation
✓ Tool-free assembly/disassembly simplifies maintenance
✓ Modular design enables quick part replacement
2. Heavy-Duty Performance
✓ Customizable for varying outputs & moisture levels
✓ Reinforced thick-plate structure withstands heavy loads
✓ Adjustable screen openings (multi-size grading)
✓ High-strength bolt motor mounting for vibration resistance
3. Advanced Vibration Control
✓ Rubber spring isolation reduces noise (<75dB)
✓ Precision amplitude adjustment for optimal dewatering
✓ Balanced vibration ensures thorough material dehydration
✓ Energy-efficient motor operation
